- Factory direct sale with ready stock machines available now
- Fast global delivery in standard 40ft container shipment
- Fully tested before dispatch with customer material verification
- Free installation training and lifetime technical support included
- Competitive factory pricing with flexible payment options offered
- Custom configuration built to your exact profile specifications
- Request video inspection of operating machine before purchase
Looking for a purlin machine for sale with reliable quality, transparent pricing, and fast global delivery? Our factory-direct cold roll forming production lines are available for immediate order with standard manufacturing lead times of 25-35 working days. Every machine undergoes a complete factory acceptance test with customer-specified material before disassembly and shipping, ensuring the equipment arrives ready for production with minimal on-site commissioning time. Whether you need an entry-level manual C purlin machine to start production, a computer-controlled multi-size line to expand capacity, or a fully automatic CZU integrated system for maximum output, we have proven configurations in current production with reference installations across 30+ countries worldwide.
| Model Category | Profile Type | Key Specifications | Production Speed | Lead Time | Best Suited For |
|---|---|---|---|---|---|
| Manual C Purlin Machine | C purlin only | 12-14 rows, 300H frame, Φ65-75 shaft, 5.5-7.5KW | 4-8 m/min | 25-30 days | New factory startup, single-size output |
| Computer C Purlin Machine | C purlin with auto adjustment | 15-18 rows, 350-400H frame, Φ80-95 shaft, 15-22KW | 6-12 m/min | 30-35 days | Growing business, multi-size batches |
| CZ Integrated Machine | C + Z automatic switching | 16-20 rows, 400-450H archway, Φ90-100 shaft, 22-30KW | 8-15 m/min | 30-35 days | Export-oriented, dual-profile market |
| CZU Flagship Machine | C + Z + U all-in-one | 24-26 rows, 400-500H archway, Φ95-120 shaft, 30-55KW | 10-18 m/min | 35-40 days | High-volume factory, maximum range |
| Item | Equipment Included | Quantity | Notes |
|---|---|---|---|
| 1 | Hydraulic Coil Decoiler | 1 unit | Cantilever or A-frame type, matched to your coil weight specification |
| 2 | Strip Leveling and Feed Guide | 1 unit | 7-roller cassette with adjustable upper bank and edge alignment |
| 3 | Hydraulic Punch Press | 1-2 units | Pre and/or post forming, with your specified hole pattern die set |
| 4 | Main Roll Forming Mill | 1 unit | Complete with specified number of stations, shafts, bearings, and roller dies |
| 5 | Profile Straightening Unit | 1 unit | Turk's head type with independent horizontal and vertical adjustment |
| 6 | Hydraulic or Flying Shear | 1 unit | With one blade set installed; spare blade set included in parts kit |
| 7 | Run-Out Conveyor Table | 2 sections | 3,000mm each section, free-roller type with adjustable side guides |
| 8 | PLC Main Control Cabinet | 1 unit | Pre-programmed, pre-wired, with 10-inch touchscreen HMI, multi-language |
| 9 | Hydraulic Power Pack | 1 unit | Complete with motor, pump, tank, manifold, valves, and initial oil charge |
| 10 | Spare Parts Kit | 1 set | Shear blades, bearings, seals, sensors, fuses, relays — first year supply |
| 11 | Maintenance Tool Box | 1 set | Complete toolkit for routine operation, adjustment, and maintenance tasks |
| 12 | Technical Documentation | 1 package | English manuals, electrical diagrams, hydraulic schematics, PLC program backup |
| 13 | Installation and Training Service | 1 deployment | Factory engineer dispatched to your site for setup, commissioning, and training |
| Optional Equipment | Function | Recommended When | Delivery Impact |
|---|---|---|---|
| Hydraulic Coil Car | Loads coils onto decoiler without crane | No overhead crane available or using 5+ ton coils | Adds 3-5 days to production time |
| Coil End Welder + Accumulator | Join coils for truly continuous production | High-volume operation with multi-coil runs | Adds 5-7 days; requires pit or horizontal accumulator |
| Automatic Stacking System | Counts, aligns, and stacks finished purlins | Over 3,000 tons annual production; labor cost reduction | Adds 5-7 days; extends line length by 2,500mm |
| Automatic Bundling Station | Straps stacked purlins into bundles | Full automation from coil to bundled product | Adds 5-7 days; requires compressed air supply |
| Laser Length Measurement | Non-contact precision length verification | Tight customer specifications on cut length tolerance | Adds 2-3 days; integrates with existing PLC |
| Inkjet Marking System | Prints part number, length, and batch on purlin | Project-based production with traceability requirements | Adds 3-5 days; includes consumable ink supply |
| Extended Run-Out Table | Supports purlins up to 12 meters long | Producing purlins longer than 6 meters regularly | Adds 1-2 days; replaces standard 3,000mm sections |
| Step | Stage | What Happens | Your Action Required |
|---|---|---|---|
| 1 | Inquiry and Consultation | You share your purlin profile dimensions, material specs, and production goals | Provide profile drawing or dimensions (width, height, lip, thickness range) and estimated monthly tonnage |
| 2 | Technical Proposal | Engineering team prepares machine specification, layout drawing, and quotation | Review proposal; confirm specifications match your requirements; ask any technical questions |
| 3 | Video Inspection | Live video call to view a similar machine in operation at existing customer factory | Observe machine producing purlins; ask the operator questions about daily performance |
| 4 | Proforma Invoice | Final commercial offer with complete scope of supply, delivery terms, and payment schedule | Review and confirm all items; request any adjustments to configuration or terms |
| 5 | Deposit Payment | 30% deposit confirms your order and reserves production slot | Arrange bank transfer or letter of credit as agreed |
| 6 | Production and Updates | Manufacturing proceeds with weekly photo progress updates | Send your material sample for production test; confirm shipping arrangements |
| 7 | Factory Acceptance Test | Machine runs production test with your material; dimensional inspection report provided | Attend in person or via video call; approve test results before shipment authorization |
| 8 | Balance Payment | 70% balance due before container loading | Arrange final payment; confirm shipping and insurance instructions |
| 9 | Shipping and Delivery | Machine packed, container loaded, documents provided, vessel departs | Receive shipping documents; arrange import customs clearance with local broker |
| 10 | Installation and Training | Engineer arrives at your factory for machine setup, commissioning, and operator training | Prepare foundation, power supply, and coil material; assign operators for training program |
| Logistics Detail | Standard Arrangement | Alternative Options |
|---|---|---|
| Port of Loading | Tianjin Xingang Port, China | Qingdao, Shanghai, or Ningbo available on request |
| Container Type | 1× 40ft high-cube container (standard C/CZ machines) | 40ft open-top or flat rack for oversized CZU machines |
| Packing Method | Steel skid with bolted tie-downs; VCI anti-rust film; reinforced wooden crates for tooling | Full wooden case vacuum packing with desiccant for long sea voyages or humid destinations |
| Shipping Documents | Bill of lading, commercial invoice, packing list, certificate of origin | Form E / Form F for ASEAN / Chile FTA; fumigation certificate; pre-shipment inspection report |
| Insurance Coverage | Buyer arranges marine cargo insurance | All-risk insurance can be arranged and included in CIF quotation upon request |
| Transit Time Reference | Southeast Asia: 7-15 days; Middle East: 20-25 days; Africa: 25-35 days; Americas: 25-40 days; Europe: 30-40 days | Air freight available for urgent small machines at premium rate; rail to Central Asia available |
| Customs Clearance | Buyer responsible for import duties, taxes, and clearance in destination country | DDP (delivered duty paid) service available to select countries upon request |
| Factory Direct Advantage | Compared to Trading Company | Compared to Used Machine |
|---|---|---|
| Pricing | No middleman markup; pay factory cost plus reasonable margin | Used machines may appear cheaper but carry hidden refurbishment, repair, and downtime costs |
| Customization | Machine built to your exact specifications; trading companies sell standard configurations | Used machines are fixed configuration; cannot be modified to match your exact profile needs |
| Quality Control | Direct oversight of manufacturing process; you can visit and inspect during production | Unknown maintenance history; worn roller dies and bearings may need immediate replacement |
| Technical Support | Engineers who built your machine provide lifetime support; know every component | No original manufacturer support; rely on general industrial mechanics for troubleshooting |
| Warranty Coverage | 12-month comprehensive warranty on all components with express parts delivery | Used machines sold as-is with no warranty; any breakdown is your cost to repair |
| Spare Parts Availability | OEM parts guaranteed available; CAD data retained for exact replication of all tooling | Parts may be obsolete or unavailable; reverse-engineering adds cost and delay |
| Training and Setup | Factory engineer installs and trains your team; machine commissioned to specification | Self-installed with no training; learning curve costs measured in scrap and lost production |
| Production Readiness | Factory tested with your material; first production piece is within specification | May require weeks of adjustment and repair before producing acceptable quality |
| Payment Method | Terms | Best For | Notes |
|---|---|---|---|
| T/T Bank Transfer | 30% deposit, 70% before shipment | Standard orders, most common method | Simple, low bank fees, fast processing |
| Letter of Credit (L/C) | Irrevocable at sight, confirmed by issuing bank | Orders over $50,000 USD equivalent | Bank guarantees payment; higher documentation requirements |
| Western Union / MoneyGram | 100% advance for spare parts orders | Small value spare parts and tooling orders | Fast processing for urgent parts under $5,000 |
| Trade Assurance (Alibaba) | Order placed through platform with buyer protection | First-time buyers wanting platform security | Additional platform fee applies; order limits may apply |
| Installment Payment | Negotiable schedule for multi-machine orders | Multiple machine purchase; long-term partnership | Subject to credit review and order value; minimum 2 machines |
| Common Pre-Purchase Question | Our Response and Commitment |
|---|---|
| "How do I know the machine will produce my exact profile correctly?" | We conduct a full production test with material you provide before shipment. You receive measurement reports for 20 consecutive pieces showing dimensional accuracy. You can witness this test in person or via live video. |
| "What if the machine arrives damaged during shipping?" | Every machine is packed in reinforced steel-skid crating with VCI anti-rust protection, bolted tie-downs, and container-optimized weight distribution. We provide full photo documentation of packed condition. In the unlikely event of shipping damage, marine insurance covers repair or replacement. |
| "Will someone come to install and train our operators?" | Yes — one factory-trained installation engineer is included in your purchase. They stay on-site until the machine is assembled, aligned, commissioned, producing your profiles, and your operators are trained and confident. Typically 5-7 working days on-site. |
| "What if we have a technical problem after installation?" | Our self-developed PLC system means most electrical issues are diagnosed and resolved through one video call. For mechanical issues, we ship replacement parts by air freight within 48 hours. Our engineering team is available 24/7 via instant messaging. |
| "Can I see a machine working before I decide?" | We arrange live video calls to show you operating machines at existing customer factories. You can ask the operator questions about daily performance, reliability, and any issues they have experienced. |
| "What guarantees do you provide on delivery time?" | Production timeline is committed in the sales contract with penalty clauses for late delivery. We provide weekly photo updates so you can track progress throughout the manufacturing period. |
Send us your purlin profile specifications for a detailed quotation within 24-48 hours. Include the following information for the most accurate price and specification:
Factory visits are welcome and encouraged. Bring your coil material and profile drawing for a live production demonstration on our test machine. No obligation — come see the quality firsthand before making your decision.
